Description

The GR32.Blur unit provides fast Gaussian blurring routines for 32-bit ARGB bitmaps (TBitmap32). It supports full-image blurs, rectangular sub-region blurs, arbitrary polygonal region blurs, 1D directional horizontal motion blurs, and gamma-aware linear light blurring.

---

High-Performance Recursive Gaussian Filtering

Standard Gaussian blurring via direct 2D spatial convolution requires $O(R^2)$ kernel multiplications per pixel, where $R$ is the blur radius. For large blur radii, standard convolution becomes computationally prohibitive.

To achieve maximum performance, GR32.Blur implements an Infinite Impulse Response (IIR) recursive Gaussian filter based on the Young, van Vliet, Triggs, and Sdika algorithms. This recursive filter processes scanlines causally (forward) and anti-causally (backward) using a small set of filter poles:

• Constant Time Complexity: Execution speed is $O(1)$ per pixel, independent of the blur radius $R$.
• Boundary Condition Correction: Applies exact boundary condition matrices at image edges to eliminate dark border bleeding or edge reflection artifacts.
• SIMD Acceleration: Core recursive filter passes utilize SSE2 / SSE4.1 vector operations on supported CPU architectures.

---

Gaussian Radius vs. Sigma ($\sigma$)

Mathematically, a 1D Gaussian distribution is defined by its standard deviation $\sigma$ (Sigma):

$$G(x)=\frac{1}{\sqrt{2\pi }\sigma }{e}^{-\frac{x^2}{2{\sigma }^2}}$$

Because the theoretical Gaussian curve extends infinitely in both directions regardless of $\sigma$, Graphics32 defines the effective pixel radius ($R$) as the distance at which kernel weights drop below 1 pixel precision threshold.

GR32.Blur provides conversion constants (GaussianRadiusToSigma and GaussianSigmaToRadius) to convert between mathematical $\sigma$ and user-facing pixel radius $R$:

$$R=\sigma \cdot \text{GaussianSigmaToRadius}$$$$\sigma =R\cdot \text{GaussianRadiusToSigma}$$

Where $\text{GaussianRadiusToSigma}\approx 0.30038663$.

---

Gamma-Aware Blurring

Standard digital image pixels are stored in non-linear gamma or sRGB color space. Performing spatial blurring directly on non-linear color values introduces physical errors:

• Dark Fringe Artifacts: High-contrast edges (such as white text on a dark background) develop an unnaturally dark ring or muddy border when blurred in gamma space.
• Luminance Loss: Intermediate blended values underestimate physical photon energy.

GR32.Blur provides gamma-aware blur routines (GammaBlur32 and GammaHorizontalBlur32). These routines convert color channels into linear light space (using precomputed tables in GR32_Gamma), perform alpha premultiplication and recursive filtering in linear space, and then convert the result back to gamma/sRGB space.

No blur	Blur without gamma	Blur with gamma

Blur: 12.0px, Gamma: 1.4

---

Region and Rectangular Masking

When blurring a sub-region (Blur32 or GammaBlur32 with TRect or TArrayOfFloatPoint), GR32.Blur dynamically selects an optimal execution path:

1. Local Sub-Bitmap Copy: If the target bounding box covers less than 75% of the total bitmap area, the unit extracts only the target region into a temporary buffer, applies an in-place blur, and composits the result back using a TBitmapPolygonFiller.
2. Full-Bitmap Masked Blur: If the region covers most of the bitmap, the full bitmap is blurred and masked back onto the source.

Removing mistakes with region blur

---

Alpha Channel Handling

All blur routines in GR32.Blur process all four 8-bit channels ($R,G,B,A$). Blurring the Alpha channel produces smooth, antialiased soft shadow edges. If alpha blurring is not desired for a specific application, save and restore the alpha channel of the TBitmap32 after calling the blur routine.

---

Minimum Blur Radius

The global variable Blur32MinRadius (default $0.5$ pixels) defines the threshold below which blur operations are skipped:

• If $\text{Radius}<\text{Blur32MinRadius}$, out-of-place blur calls perform a fast direct copy, while in-place calls exit immediately.
